Description
CHARACTERISTIC
| Sparker Test | 4000 Vac |
| Impedance | 75 ± 3 Ohm |
| Capacitance | 54 ± 3pF/m |
| Velocity Of Propagation | 85% |
ATTENUATION
| Frequency Range | RG-11 (dB/100m) |
| 5 Mhz | 1.25 |
| 55 Mhz | 3.15 |
| 200 Mhz | 3.92 |
| 250 Mhz | 6.72 |
| 350 Mhz | 7.94 |
| 450 Mhz | 9.02 |
| 500 Mhz | 9.51 |
| 600 Mhz | 10.43 |
| 750 Mhz | 11.97 |
| 870 Mhz | 13.09 |
| 1000 Mhz | 14.27 |
SPECIFICATION
| Conductor | Material | Copper Clad Steel | |
| Nom Diameter | 1,63 mm | ||
| Dielectric | Material | Polyethylene HDPE | |
| Nom Diameter | 7,11 mm | ||
| Shield | Material | Aluminium Foil bonded to dielectric | |
| Nom Diameter | 76% | ||
| Jacket | Material | PVC | |
| Nom Diameter | 10,01 mm | ||
| Jacket Thickness | 7,07 mm | ||
| Impedance | 75 Ω | ||
