Description
SPECIFICATIONS
| RF INPUTS | BI-FM | AUX | VHF/UHF 1 | VHF/UHF 2 | UHF 3 | UHF 4 | |||
|---|---|---|---|---|---|---|---|---|---|
| FREQUENCY RANGE (MHZ) | 40-108 | 40-862 | 170-320 + 470-694/790/862 (depending on selected LTE SAW filter) | ||||||
| CHANNELS | 2-4 + FM | 2-69 | 5-12 + S11-S21 + 21-48/60/69 (depending on selected LTE SAW filter) | ||||||
| FILTERS | 1 | 1 | 32 | ||||||
| NUMBER OF CHANNELS PER FILTER | – | – | 1 or 2 (selectable) | ||||||
| MUX CONVERSION | – | Yes | |||||||
| UHF FILTERS SELECTIVITY | – | – | 35 dB @ +/- 1MHz | ||||||
| INPUT STAGE GAIN ADJUST | 0 to -30 dB | 0 to -20 dB | 0 to -20 dB | 0 to -20 dB | 0 to -20 dB | 0 to -20 dB | |||
| AGC DYNAMIC RANGE | 40 dB | 40 dB | 40 dB | 40 dB | |||||
| OUTPUT-STAGE GAIN ADJUST | 0 to -20 dB | ||||||||
| MAX. GAIN | 45 dB | 40 dB | VHF: 40 dB, UHF:50 dB | ||||||
| NOISE FIGURE | <6 dB | <6 dB | <6 dB | ||||||
| MAX. OUTPUT SIGNAL | 120dBµV (*p version:124dBµV) (IM3 DIN 45004B – 60 dBc) | ||||||||
| TILT/SLOPE | – | – | 0 to 5dB | ||||||
| TEST OUTPUT LEVEL | -30dB | ||||||||
| INPUT/OUTPUT RETURN LOSS | >12 dB | ||||||||
| GENERAL | |||||||
|---|---|---|---|---|---|---|---|
| IN/OUT CONNECTORS | “F” female | ||||||
| USB | USB 1.0 / 2.0 Type B | ||||||
| PREAMPLIFIER REMOTE POWERING | OFF, 12VDC or 24VDC 100mA @ each input (2.4W in total) | ||||||
| POWER SUPPLY | External power supply. Input: 230VAC +/-10% 16W. Output: 20VDC/2.25Amp | ||||||
| SET UP | Built-in programmer with display and keyboard, Android or Windows PC Apps | ||||||
| TEMPERATURE | Operating: -5º to 50ºC, up to 90% humidity | ||||||
| INCLUDED | 1 x External power supply. Mains cable: Europlug CEE7/16 to IEC 60320-C7 VDE 2.5A/250V | ||||||
| DIMENSIONS | Amplifier: 192x217x37mm | ||||||
| GROSS WEIGHT | Unit: 2.1Kg. | ||||||
| NOTE | Silent operation. Fan-less | ||||||
