| Layer |
2 |
| Connectivity |
| 10/100 Base-TX (RJ45) ports |
8 |
| 100/1000 Base-X (SFP) ports |
2 |
| Performance |
| Switching matrix |
5,6 Gbps |
| Data rate |
4,2 Mpps |
| Packet buffer |
0,5 MB |
| JUMBO frame |
10 K |
| MAC address table |
8 K |
| Multicast support |
500 |
| MAC address table additional info |
MAC address table shared for unicast and multicast (in 1:1 ratio) |
| ACL Table |
1,4 K |
| Number of Vlan Interfaces (IP) |
16 |
| CPU clock |
400 MHz |
| Flash memory |
32 MB |
| RAM memory |
128 MB |
| Features |
| Resilience and availability |
IEEE 802.1D (STP), IEEE 802.1w (RSTP), IEEE 802.1 s (MSTP), IEEE 802.3 ad LACP, Virtual Cable Testing, DDM, LLDP, Loop Guard, ERPS (ITU-T G.8032) |
| Traffic control |
IEEE 802.1Q, Port-based VLAN, Protocol-based VLAN, IP subnet based VLAN, Voice VLAN, MAC VLAN, Super VLAN, LACP algorithm of source/destination IP (load balance), GVRP, IEEE 802.1ad Vlan Stacking (QinQ), Selective QinQ, Flexible QinQ |
| Security |
Layer 2 MAC filtering, BPDU Tunnel, Login authentication and authorization by RADIUS and TACACS+, Tacacs+ accounting/auditing, SSH v1/v2, DHCP/DCHPv6 Snooping, IPv4/IPv6 Source Guard, Port Security, IEEE 802.1x port-based/mac-based |
| QoS |
IEEE 802.1p Priority Queues per Port (8 Queues), IEEE 802.1p Quering method, Trusted COS/TOS/IP Precedence/DSCP/Port, Broadcast Storm Control, Rate Limiting port based, Strict Priority, Weighted Round Robin, Weighted Deficit Round Robin, |
| L2/L3 Multicast |
Multicast VLAN, IGMP (v1/v2/v3), IGMP Query, IGMP Snooping (v1/v2/v3), IGMP Snooping Fast Leave (v2,v3), IPv6 MLD v1/v2 Snooping |
| Management |
Console Port RS-232 (RJ45), GUI (Web), telnet, SNMP (v1/v2c/v3), TFTP/FTP, Configuration backup and restore, Multilevel CLI, DNS Client, DHCP (Client/Relay/Server), DHCP Relay per VLAN, DHCP (Option 43/60/82), DHCPv6 (Option 37/38), DHCPv6 (Relay/Server), NTP/SNTP, sFlow, Port Mirroring (per IP/TCP/UDP), RSPAN, Cluster, IEEE 802.3ah EFM, IEEE 802.1ag CFM |
| Electrical |
| PoE standard supported |
- IEEE 802.3af (PoE)
- IEEE 802.3at (PoE+)
|
| PoE power budget |
240 W |
| Fans |
Fanless |
| Power supply |
50 – 57 V DC |
| Redundant power supply |
50 – 57 V DC |
| Maximal power consumption |
250 W |
| Physical |
| Mounting type |
DIN |
| Protection mode |
IP40 |
| Operating temperature |
-40|85 ℃ |
| Relative humidity |
10|90 % |
| Dimensions (Width x Height x Depth) |
60mm x 165mm x 140mm |
