Description
SPECIFICATIONS
| Frequency Range | : 48 to 860 MHz Agility |
| Output Level | : 60 dBmV |
| Audio / Video Ratio | : -7 to -40 dB (Adjustable) |
| Output Impedance : | : 75 ohm |
VIDEO
| Input Level (Adjustable) | : 1V p-p (Load) |
| Frequency Response | : ±1 dB |
| Video C/N | : >= 60 dBc |
| Video S/N | : >= 55 dBc |
| Video Modulation | : 0-90% Adjustable |
| Differential Phase | : ±3° typical |
| Differential Gain | : ±3° typical |
| Group Delay | : 75usec |
AUDIO
| Input Level (Adjustable) | : 1V p-p for ±30KHz peak Deviation |
| Carrier Stability | : ± 5 kHz |
| Frequency Response | : ± 1 dB |
| Input Impedance | : High Impedance |
GENERAL
| Connections | : “F” type Rear Panel Connectors |
| Power Input | : 90-260VAC, 50/60Hz, Switching Power |
| Dimensions | : 19”L × 8.10”W × 1.75”H |
