Description
| Attributes |
IS2100D |
||
|
Technology |
|||
| Standards |
IEEE 802.3u for 100BaseT(X) and 100BaseFX IEEE 802.3ab for 1000BaseT(X) IEEE 802.3z for 1000BaseX IEEE 802.3x for Flow Control IEEE 802.1D-2004 for Spanning Tree Protocol IEEE 802.1w for Rapid STP IEEE 802.1s for Multiple Spanning Tree Protocol IEEE 802.1Q for VLAN Tagging IEEE 802.1p for Class of Service IEEE 802.1X for Authentication IEEE 802.3ad for Port Trunk with LACP |
||
|
Performance |
|||
|
Forwarding Rate |
10Mbps:14880pps 100Mbps:148800pps 1000Mbps:1488000pps |
||
|
Switching Capacity |
IS2100D-2GF8TX: 9.6Gbps IS2100D-4GF10GT: 28Gbps IS2100D-2GF4GT-P: 12Gbps IS2100D-2GF8GT-P: 20Gbps IS2100D-4GF10GT-P: 28Gbps |
||
|
IGMP groups |
IS2100D-2GF8TX: 4K Other: 1K |
||
|
MAC Table Size |
8K |
||
|
VLAN number available |
4K |
||
|
Priority Queues |
8 |
||
|
Buffer size |
IS2100D-2GF8TX: 32M Other: 4M |
||
|
ACL rules |
IS2100D-2GF8TX: 512 Other: 256 |
||
|
Jumbo Frame |
IS2100D-2GF8TX: 2048 bytes Other: 9K bytes |
||
|
Ports |
|||
|
Fixed Ports |
IS2100D-2GF8TX |
8 * 10/100Base-TX 2 * 100/1000BaseX SFP |
|
|
IS2100D-4GF10GT |
10 * 10/100/1000Base-TX 4 * 100/1000BaseX SFP |
||
|
IS2100D-2GF4GT-P |
4 * 10/100/1000Base-TX 2 * 100/1000BaseX SFP |
||
|
IS2100D-2GF8GT-P |
8 * 10/100/1000Base-TX 2 * 100/1000BaseX SFP |
||
|
IS2100D-4GF10GT-P |
10 * 10/100/1000Base-TX 4 * 100/1000BaseX SFP |
||
|
Management Port |
Console |
||
|
LED Light |
POWER, Management Status, Link/Active and Transceiver |
||
|
Port Trunk |
Support IEEE802.3ad, LACP |
||
|
Port Mirroring |
Port monitor 1:1, n:1 |
||
|
Bandwidth Control |
Steps 64kbps |
||
|
Storm Control |
Support Broadcast / Multicast / Unicast Storm Control |
||
|
Port Protection |
Support MAC binding , MAC address filter, MAC limit |
||
|
Port Loop Detection |
Support |
||
|
Port Isolation |
Support |
||
|
Main feature |
|||
|
Forwarding Mode |
Storage and Forwarding |
||
|
VLAN |
Port-based VLAN Support IEEE 802.1Q, up to 4094 VLANs MAC-based VLAN Protocol-based VLAN Private VLAN GVRP Normal QinQ, selective QinQ |
||
|
DHCP |
IPv4/IPv6 DHCP Client,IPv4/IPv6 DHCP Relay Option 82,Option 37/38 IPv4/IPv6 DHCP Snooping, IPv4/IPv6 DHCP Server |
||
|
Reliability |
Spanning Tree |
802.1D STP, 802.1W RSTP, 802.1S MSTP Root Guard, BPDU Guard, BPDU Forwarding |
|
|
LACP |
LACP support Load balance |
||
|
L2 Ring Protection |
Ring protection protocol (ERPS) Loopback Detection |
||
|
Security |
IP ACL, MAC ACL, MAC-IP ACL, User-Defined ACL Port Security,MAC Limit based on Port ARP Binding ARP Inspection IEEE 802.1x, MAB (MAC based authentication) Authentication, Authorization, Accounting Radius |
||
|
Multicast |
IGMP v1/v2 snooping IGMP packet filtering Multicast control |
||
|
QoS |
8 Queues Bandwidth Control Classification based on COS,DPL,PCP,DEL,IPV4 Policing Based on Port Remark COS/802.1p, DPL, DSCP SP, WRR for scheduling |
||
|
Maintenance and Operation Management |
TFTP CLI, Telnet, Console, SSH Web/SSL SNMPv1/v2c Public & Private MIB interface RMON 1,2,3,9 Ping, Trace Route Radius Authentication Syslog (IPv4) SNTP (IPv4) Dual IMG, Multiple Configuration Files Port Mirror LLDP |
||
|
Green Energy |
Fanless design |
||
|
Hardware Specs |
|||
|
Dimension(W x D x H) |
IS2100D-2GF8TX: 53mm×125mm×135mm(W×D×H) IS2100D-4GF10GT: 45mm×145mm×165mm (W×D×H) IS2100D-2GF4GT-P: 53mm×125mm×135mm (W×D×H) IS2100D-2GF8GT-P: 55mm×145mm×165mm(W*D*H) IS2100D-4GF10GT-P: 45mm×145mm×165mm(W*D*H) |
||
|
Weight |
<1kg |
||
|
Installation |
Din-Rail |
||
|
Others |
Fanless, IP40 protection |
||
|
Electrical Performance |
|||
|
Input Voltage |
IS2100D-2GF8TX: 24VDC (18 ~36VDC) IS2100D-4GF10GT: 48VDC (46 ~57VDC) IS2100D-2GF4GT-P: 48VDC (46 ~57VDC) IS2100D-2GF8GT-P: 48VDC (46 ~57VDC) IS2100D-4GF10GT-P: 48VDC (46 ~57VDC) |
||
|
Power Consumption |
IS2100D-2GF8TX: <10Watts Other: <20Watts |
||
|
Working Environment |
|||
|
Working Temperature |
-40 to 75 ℃ |
||
|
Storage Temperature |
-45 to 75 ℃ |
||
|
Relative Humidity |
10% ~ 95%, Non-condensing |
||
|
Redundancy |
|||
|
Network Redundancy |
Support Ring Protection, <50ms Support single, dual and tangent ring Support STP/RSTP/MSTP |
||
|
Port Redundancy |
Support Port Trunk Ring protection protocol(ERPS) |
||
|
Standard and Certification |
|||
|
ISO |
ISO9001:2008 |
||
|
EMI |
FCC Part 15 (Class A), EN55022 (CISPR22 Class A), EN55024 (Class A), CE, EN50121-3-2, EN50121-4 IEC61850 |
||
|
EMC |
EN61000-4-2, EN61000-4-3, EN61000-4-4 EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-12 |
||
|
Safety |
EN60950, UL508/cUL508, UL1604/cUL1604 |
||
