Specifications
Item |
S5750E-28X-P-EI (R2) |
Physical port |
20 x 10/100/1000BaseT + 4 x GE Combo (GT/SFP) + 4 x 10GE(SFP+) Auto-MIDX |
Management port |
1 x RJ45 Ethernet Management port |
1 x Console port |
|
1 x Reset port |
|
1 x USB2.0 interface |
|
Performance |
|
Switching Capacity |
128Gbps |
Forwarding rate |
95Mpps |
Jumbo Frame | 10K |
MAC Address |
16K |
ARP Table |
4K |
Routing Table |
1K |
ACL Table |
1K |
Physical |
|
Dimension (W*H*D) | 440mm x 44mm x 320mm |
Relative Humidity | 5%~95% non-condensing |
Temperature | Working 0°C~50°C, storage -40°C~70°C |
Power Supply | AC:100~240VAC, 50~60Hz |
Power Consumption | <471W |
PoE |
IEEE 802.3af IEEE 802.3at Total PoE power: 370W |
Main Features |
|
L1, L2 Features |
IEEE802.3(10Base-T), IEEE802.3u(100Base-TX), IEEE802.3z(1000BASE-X), IEEE802.3ab(1000Base-T), IEEE802.3ae(10GBase), IEEE802.3x, IEEE802.3ak(10GBASE-CX4) |
Port loopback detectionLLDP and LLDP-MEDULDP802.3ad LACP, max 128 group trunks with max 8 ports for each trunk (S5750E-52X-P-SI (R2.0) support max 64 group trunks with max 8 ports for each trunk)LACP load balanceERPS (G.8032) | |
N:1 Port Mirroring RSPAN |
|
IEEEE802.1d(STP) IEEEE802.1w(RSTP) IEEEE802.1s(MSTP) Root Guard BPDU Guard BPDU Tunnel |
|
802.1Q, 4K VLAN MAC VLAN, Voice VLAN, PVLAN, Protocol VLAN, Multicast VLAN QinQ, Flexible QinQ GVRP N:1 VLAN Translation Broadcast / Multicast / Unicast Storm Control |
|
IGMP v1/v2/v3 Snooping and L2 QueryND SnoopingMLDv1/v2 Snooping | |
Port Security |
|
Flow Control: HOL, IEEE802.3xBandwidth Control | |
L3 Features | Static Routing, RIPv1/v2, OSPFv2, BGP4OSPFv3, BGP4+OSPF multiple processesLPM RoutingPolicy-based routing (PBR) for IPv4 and IPv6VRRPURPF,ECMPBFD |
IGMP v1/v2/v3, IGMP Proxy,Static Multicast RouteMulticast Receive ControlIllegal Multicast Source Detect | |
ARP Guard, Local ARP proxy, Proxy ARP, ARP Binding, Gratuitous ARP, ARP LimitAnti ARP Cheat, Anti ARP Scan | |
DNS Client, DNS Relay | |
GRE Tunnel (S5750E-52X-P-SI (R2.0) doesn’t support) | |
IPv6 | 6to4 Tunnel, Configured Tunnel, ISATAP Tunnel, GRE Tunnel (S5750E-52X-P-SI(R2) don’t support)ICMPv6, ND, DNSv6IPv6 LPM Routing, IPv6 Policy-based Routing (PBR)IPv6 VRRPv3, IPv6 URPF, IPv6 RARIPng, OSPFv3, BGP4+MLD Snooping, IPv6 Multicast VLANMLDv1/v2, IPv6 ACL, IPv6 QoS |
QoS | 8 QueuesSP, WDRR, SWDRRTraffic Classification Based on 802.1p COS, ToS, DiffServ DSCP, ACL, port numberTraffic PolicingPRI Mark/Remark |
ACL | IP ACL, MAC ACL, IP-MAC ACL, User-Defined ACLStandard and Expanded ACL Based on source/destination IP or MAC, IP Protocol, TCP/UDP port, DSCP, ToS, IP Precedence), VLAN, Tag/Untag, CoSRedirect and statisticsRules can be configured to port, VLANTime Ranged ACLACL rules can be configured to port, VLAN |
Security | 802.1x AAAPort, MAC-based authenticationAccounting based on time length and trafficGuest VLAN and auto VLAN |
RADIUS for IPv4 and IPv6 | |
TACACS+ for IPv4 and IPv6 | |
MAB | |
DHCPv4/v6Traffic Monitor | DHCP Server/Client for IPv4/IPv6DHCP Relay/Option 82DHCP Snooping/Option 82 |
Traffic Monitor | sFlow Traffic Analysis |
Security Network Management | CLI, WEB, Telnet, SNMPv1/v2c/v3 through IPv4 and IPv6Syslog and external Syslog ServerHTTP SSLSNMP MIB, SNMP TRAPFTP/TFTPSNTP/NTPRMOM 1,2,3,9Authentication by Radius/TACACSSSH v1/v2Dual firmware images/ Configuration files802.3ah OAM, 802.1ag OAM |
Data Center Features | VSF (Virtual Switch Framework) |
